Save time and draft with confidence using this bundle of CAD symbols for electrical and lighting plans.
Electrical symbols: Outlets (duplex, GFI, USB, quadplex, recessed data/TV) and switches (standard, dimmers, 3-way/4-way, fan, manual-on, counter).
Lighting symbols: 24 versatile lighting options, including can lights, pendants, wall sconces, downlights, utility lights, fans, ceiling lights, smoke/CO detectors, and more — all selectable and rotatable.
This bundle ensures fast, accurate, and consistent layouts for your projects.
